  Chevrolet Corvette C4 ZR-1


  Article Image gallery (3) Specifications User Comments (3)
Click here to open the Chevrolet Corvette C4 ZR-1 gallery
Country of origin:United States
Produced from:1989 - 1995
Numbers built:7025
Designed by:Jerry Palmer for Chevrolet
Author:Wouter Melissen
Last updated:December 31, 2004
Download: All images

Engine
Configuration LT5 90º V8
Location Front, longitudinally mounted
Construction alloy block and head
Displacement 5,727 cc / 349.5 cu in
Bore / Stroke 99.0 mm (3.9 in) / 93.0 mm (3.7 in)
Compression 11.0:1
Valvetrain 4 valves / cylinder, DOHC
Fuel feed Rochester Fuel Injection
Aspiration Naturally Aspirated
Power 405 bhp / 302 KW @ 5,800 rpm
Torque 522 Nm / 385 ft lbs @ 5,200 rpm
BHP/Liter 71 bhp / liter

Drivetrain
Chassis fibreglass body on tubular steel spaceframe
Front suspension double wishbones, transverse leaf spring, tubular shock absorbers, anti-roll bar
Rear suspension multi-link, transverse fibreglass leaf spring, tubular shock absorbers, anti-roll bar
Steering rack-and-pinion, power assisted
Brakes ventilated discs, all-round, ABS
Gearbox ZF 6 speed Manual
Drive Rear wheel drive

Dimensions
Weight 1,590 kilo / 3,505 lbs
Length / Width / Height 4,506 mm (177.4 in) / 1,880 mm (74 in) / 1,186 mm (46.7 in)
Wheelbase / Track (fr/r) 2,443 mm (96.2 in) / 1,514 mm (59.6 in) / 1,572 mm (61.9 in)

Performance figures
Power to weight 0.25 bhp / kg
Top Speed 274 km/h (170 mph)
0-60 mph 4.9 s
0-100 mph 11.5 s
