Engine
|
Configuration |
Straight 8
|
Location |
Front, longitudinally mounted
|
Displacement |
2,262 cc / 138 cu in |
Bore / Stroke |
60.0 mm (2.4 in) / 100.0 mm (3.9 in)
|
Valvetrain |
3 valves / cylinder, DOHC
|
Fuel feed |
Solex or Zenith Carburettor
|
Aspiration |
Roots-Type Supercharger |
Power |
120 bhp / 90 kW
|
BHP/Liter |
53 bhp / liter |
Drivetrain |
Front suspension |
rigid axle, half elliptic springs |
Rear suspension |
rigid axle, reversed half elliptic springs |
Brakes |
drums, all-round |
Gearbox |
4 speed Manual
|
Drive |
Rear wheel drive |
Dimensions |
Wheelbase / Track (fr/r) |
2,970 mm (116.9 in) / 1,250 mm (49.2 in) / 1,250 mm (49.2 in)
|
Performance figures |
Top Speed |
170 km/h (106 mph)
|
Resources |
Suggested reading |
- Bugatti Magnum, by Hugh Conway with Maurice Sauzay
- Bugatti - le Pur Sang des Automobiles, by Hugh Conway
- Grand Marques Bugatti, by Hugh Conway
|
