Engine
|
Configuration |
Chevrolet 90º V8
|
Location |
Mid, longitudinally mounted
|
Construction |
aluminium block and head
|
Displacement |
5,736 cc / 350 cu in |
Bore / Stroke |
101.7 mm (4 in) / 88.4 mm (3.5 in)
|
Compression |
13.5:1 |
Valvetrain |
2 valves / cylinder, OHV
|
Fuel feed |
Fuel Injection
|
Aspiration |
Naturally Aspirated |
Power |
620 bhp / 463 kW
@ 7,750 rpm
|
BHP/Liter |
108 bhp / liter |
Drivetrain |
Body |
kevlar / carbon fibre body |
Chassis |
honeycomb aluminium monocoque with semi-stressed engine |
Suspension (fr/r) |
double wishbones, coil springs over dampers, anti-roll bar |
Steering |
rack-and-pinion |
Brakes |
ventilated discs, all-round |
Gearbox |
5 speed Manual
|
Drive |
Rear wheel drive |
Dimensions |
Weight |
900 kilo / 1,984 lbs |
Wheelbase / Track (fr/r) |
2,685 mm (105.7 in) / 1,565 mm (61.6 in) / 1,539 mm (60.6 in)
|
Performance figures |
Power to weight |
0.69 bhp / kg |
Resources |
Suggested reading |
- March, The Rise and Fall of a Motor Racing Legend, by Mike Lawrence
- Golden Era - The history of Group C & IMSA GTP, by Ian Briggs and John Starkey
|
