  Ferrari 801


Ferrari 801
Click here to save all images    Image credits: Ferrari S.P.A.

Click here to download printer friendly version Ferrari's weapon for the the 1957 Formula 1 season was again based on Vittorio Jano's Lancia D50. Both its chassis and engine were modified which earned it a new name, 801. Ferrari's 1956 championship driver, Juan Manuel Fangio, had moved back to Maserati. His old team-mate Stirling Moss moved to Vanwall. These two drivers were in a league of their own, with Fangio winning the first three races and his fifth world championship. Three second-place finishes were the best the Scuderia could manage.

After the successful 1956 season, the 1957 season was a very bad one. The 801 was outpaced and two of the drivers died early in the season. Alfonso de Portago had a horrific accident in the Mille Miglia, killing the driver, the co-driver and eleven people crowd. It was a blow for the organisers as well and the Mille Miglia was never run again.

At the factory work on a new engine and chassis was started for the 1958 season. Based on the dominating 156 F2 car with an enlarged V6 engine, it brought Ferrari back on top.

Article by Wouter Melissen, last updated before 12 / 01 / 2004

Add your comments on the Ferrari 801



General specifications
Country of origin Italy
Numbers built 3
Produced in 1957
Predecessor
Successor

Engine
Configuration 90º V8
Location Front, longitudinally mounted
Displacement 2.486 liter / 151.7 cu in
Bore / Stroke 76.0 mm (3 in) / 68.5 mm (2.7 in)
Compression 11.0:1
Valvetrain 2 valves / cylinder, DOHC
Fuel feed 2 Solex 40 PIL Carburettors
Aspiration Naturally Aspirated
Power 275 bhp / 205 KW @ 8400 rpm
BHP/Liter 111 bhp / liter

Drivetrain
Chassis aluminium body on tubular chassis
Front suspension double wishbones, coil springs, telescopic dampers and anti-roll bar
Rear suspension DeDion axle, 2 longitudinal struts, transverse upper leaf spring, Houdaille lever dampers
Steering worm and sector
Brakes finned drums, all-round
Gearbox 5 speed Manual
Drive Rear wheel drive

Dimensions
Weight 650 kilo / 1433 lbs
Length / Width / Height 3850 mm (151.6 in) / 1448 mm (57 in) / 962 mm (37.9 in)
Wheelbase / Track (fr/r) 2280 mm (89.8 in) / 1305 mm (51.4 in) / 1334 mm (52.5 in)

Performance figures
Power to weight 0.42 bhp / kg
