| Engine
|
| Configuration |
Lotus 907 Straight 4
|
| Location |
Front, longitudinally mounted
|
| Construction |
aluminium alloy block and head
|
| Displacement |
1,973 cc / 120.4 cu in |
| Bore / Stroke |
95.2 mm (3.7 in) / 69.3 mm (2.7 in)
|
| Compression |
8.4:1 |
| Valvetrain |
4 valves / cylinder, DOHC
|
| Fuel feed |
2 Dell'Orto Carburettors
|
| Aspiration |
Naturally Aspirated |
| Power |
144 bhp / 107 kW
@ 6,500 rpm
|
| Torque |
182 Nm / 134 ft lbs
@ 5,000 rpm
|
| BHP/Liter |
73 bhp / liter |
| Drivetrain |
| Chassis |
steel monocoque |
| Front suspension |
wishbones, coil springs, telescopic shock absorbers, anti-roll bar |
| Rear suspension |
live axle, diagonal links, coil springs, telescopic dampers |
| Steering |
rack-and-pinion |
| Brakes |
discs front, drums rear |
| Gearbox |
5 speed Manual
|
| Drive |
Rear wheel drive |
| Dimensions |
| Weight |
1,097 kilo / 2,419 lbs |
| Length / Width / Height |
4,216 mm (166 in) / 1,607 mm (63.3 in) / 1,232 mm (48.5 in)
|
| Wheelbase / Track (fr/r) |
2,337 mm (92 in) / 1,351 mm (53.2 in) / 1,334 mm (52.5 in)
|
| Performance figures |
| Power to weight |
0.13 bhp / kg |
| Top Speed |
193 km/h (120 mph)
|
| 0-60 mph |
8.7 s |
|
