| Engine
|
| Configuration |
90º V8
|
| Location |
Front, longitudinally mounted
|
| Construction |
alloy block and head
|
| Displacement |
3,168 cc / 193.3 cu in |
| Bore / Stroke |
82.0 mm (3.2 in) / 75.0 mm (3 in)
|
| Compression |
7.2:1 |
| Valvetrain |
2 valves / cylinder, OHV
|
| Fuel feed |
1 Zenith 32 NDIX Carburettor
|
| Aspiration |
Naturally Aspirated |
| Power |
120 bhp / 90 kW
@ 4,800 rpm
|
| Torque |
218 Nm / 161 ft lbs
@ 2,000 rpm
|
| BHP/Liter |
38 bhp / liter |
| Drivetrain |
| Chassis |
steel body on box-type chassis |
| Front suspension |
double wishbones, torsion bars |
| Rear suspension |
live axle, torsion bars, torque reaction couplings, hydraulic dampers |
| Steering |
recirculating ball |
| Brakes |
drums, all-round |
| Gearbox |
4 speed Manual
|
| Drive |
Rear wheel drive |
| Dimensions |
| Weight |
1,400 kilo / 3,087 lbs |
| Length / Width / Height |
4,730 mm (186.2 in) / 1,780 mm (70.1 in) / 1,530 mm (60.2 in)
|
| Wheelbase / Track (fr/r) |
2,835 mm (111.6 in) / 1,330 mm (52.4 in) / 1,416 mm (55.7 in)
|
| Performance figures |
| Power to weight |
0.09 bhp / kg |
| Top Speed |
170 km/h (106 mph)
|
| 0-60 mph |
14.5 s |
|
