| Engine
|
| Configuration |
Straight 4
|
| Location |
Front, longitudinally mounted
|
| Construction |
cast-iron block and head
|
| Displacement |
10,008 cc / 610.7 cu in |
| Bore / Stroke |
130.0 mm (5.1 in) / 190.0 mm (7.5 in)
|
| Valvetrain |
4 valves / cylinder, SOHC
|
| Fuel feed |
Carburettor
|
| Ignition |
Twin Spark |
| Lubrication |
Wet sump |
| Aspiration |
Naturally Aspirated |
| Power |
120 bhp / 90 kW
@ 1,650 rpm
|
| BHP/Liter |
12 bhp / liter |
| Drivetrain |
| Chassis |
steel ladder frame |
| Suspension (fr/r) |
rigid axle, semi-elliptic leaf springs |
| Brakes |
contracting bands on the transmission |
| Gearbox |
4 speed Manual
|
| Clutch |
Multi-plate |
| Drive |
Rear wheel drive |
| Dimensions |
| Weight |
1,422 kilo / 3,135 lbs |
| Wheelbase / Track (fr/r) |
3,124 mm (123 in) / 1,435 mm (56.5 in) / 1,435 mm (56.5 in)
|
| Performance figures |
| Power to weight |
0.08 bhp / kg |
| Top Speed |
160 km/h (99 mph)
|
