| Engine
|
| Configuration |
Honda RA166-E 80º V6
|
| Location |
Mid, longitudinally mounted
|
| Construction |
aluminium alloy block and head
|
| Displacement |
1,494 cc / 91.2 cu in |
| Bore / Stroke |
79.0 mm (3.1 in) / 50.8 mm (2 in)
|
| Valvetrain |
4 valves / cylinder, DOHC
|
| Fuel feed |
Fuel Injection
|
| Aspiration |
Twin Turbos |
| Power |
1,034 bhp / 771 kW
@ 11,600 rpm
|
| BHP/Liter |
692 bhp / liter |
| Drivetrain |
| Chassis |
carbon-fibre composite monocoque with fully stressed engine |
| Front suspension |
double wishbones, push-rod actuated springs and dampers, anti-roll bar |
| Rear suspension |
double wishbones, pull-rod actuated springs and dampers, anti-roll bar |
| Steering |
Rack-and-pinion |
| Brakes (fr/r) |
AP Racing ventilated carbon ceramic discs |
| Gearbox |
Williams / Hewland 6 speed Manual
|
| Drive |
Rear wheel drive |
| Dimensions |
| Weight |
540 kilo / 1,191 lbs |
| Wheelbase / Track (fr/r) |
2,794 mm (110 in) / 1,803 mm (71 in) / 1,651 mm (65 in)
|
| Fuel tank |
195 Litre (51.5 Gallon US / 42.9 Gallon Imperial)
|
| Tyres |
Goodyear |
| Performance figures |
| Power to weight |
1.91 bhp / kg |
