| Engine
|
| Configuration |
Straight 4
|
| Location |
Front, longitudinally mounted
|
| Construction |
light alloy block and head
|
| Displacement |
1,962 cc / 119.7 cu in |
| Bore / Stroke |
84.0 mm (3.3 in) / 88.5 mm (3.5 in)
|
| Compression |
9.1:1 |
| Valvetrain |
2 valves / cylinder, DOHC
|
| Fuel feed |
2 Carburettors
|
| Aspiration |
Naturally Aspirated |
| Power |
128 bhp / 95 kW
@ 5,500 rpm
|
| Torque |
177 Nm / 131 ft lbs
@ 4,000 rpm
|
| BHP/Liter |
65 bhp / liter |
| Drivetrain |
| Chassis |
unitary steel |
| Front suspension |
double wishbone, coil springs, telescopic dampers, anti-roll bar |
| Rear suspension |
independent, coil springs, telescopic dampers, anti-roll bar |
| Steering |
rack-and-pinion |
| Brakes |
discs, all-round |
| Gearbox |
5 speed Manual
|
| Drive |
Rear wheel drive |
| Dimensions |
| Weight |
1,161 kilo / 2,560 lbs |
| Length / Width / Height |
4,247 mm (167.2 in) / 1,630 mm (64.2 in) / 1,290 mm (50.8 in)
|
| Wheelbase / Track (fr/r) |
2,250 mm (88.6 in) / 1,330 mm (52.4 in) / 1,280 mm (50.4 in)
|
| Performance figures |
| Power to weight |
0.11 bhp / kg |
| Top Speed |
196 km/h (122 mph)
|
| 0-60 mph |
9.8 s |
| Resources |
| Suggested reading |
- Alfa Romeo Tutte le Vetture Dal 1910, by Luigi Fusi
|
