| Engine
|
| Configuration |
LT7 90º V8
|
| Location |
Mid, longitudinally mounted
|
| Construction |
cast aluminium block and head
|
| Displacement |
5,500 cc / 335.6 cu in |
| Bore / Stroke |
104.3 mm (4.1 in) / 80.0 mm (3.1 in)
|
| Compression |
9.8:1 |
| Valvetrain |
4 valves / cylinder, DOHC
|
| Fuel feed |
Direct Fuel Injection
|
| Lubrication |
Dry sump |
| Aspiration |
Twin Turbo |
| Power |
1,067 bhp / 796 kW
@ 7,000 rpm
|
| Torque |
1,123 Nm / 828 ft lbs
@ 6,000 rpm
|
| BHP/Liter |
194 bhp / liter |
| Drivetrain |
| Suspension (fr/r) |
double wishbones, monotube shock absorbers, magnetic ride control, anti-roll bar |
| Steering |
rack-and-pinion, power assisted, variable ratio |
| Front Brakes |
ventilated carbon ceramic discs, 400mm (15.7 in), 6-pot caliper, ABS |
| Rear brakes |
ventilated carbon ceramic discs, 390mm (15.4 in), 4-pot caliper, ABS |
| Gearbox |
M1K 8 speed Automatic
|
| Clutch |
Dual clutch |
| Drive |
Rear wheel drive |
| Dimensions |
| Weight |
1,705 kilo / 3,759 lbs |
| Length / Width / Height |
4,722 mm (185.9 in) / 2,025 mm (79.7 in) / 1,234 mm (48.6 in)
|
| Wheelbase / Track (fr/r) |
2,723 mm (107.2 in) / 1,685 mm (66.3 in) / 1,678 mm (66.1 in)
|
| Fuel tank |
70 Litre (18.5 Gallon US / 15.4 Gallon Imperial)
|
| Wheels (fr/r) |
10 x 20 / 13 x 21 |
| Tyres (fr/r) |
275/30 – ZR20 / 345/25 – ZR21 |
| Performance figures |
| Power to weight |
0.63 bhp / kg |
