| Engine
|
| Configuration |
Straight 8
|
| Location |
Front, longitudinally mounted
|
| Construction |
cast-iron block and head
|
| Displacement |
1,496 cc / 91.3 cu in |
| Bore / Stroke |
52.0 mm (2 in) / 88.0 mm (3.5 in)
|
| Valvetrain |
3 valves / cylinder, SOHC
|
| Fuel feed |
Zenith Carburettor
|
| Aspiration |
Roots-Type Supercharger |
| Power |
120 bhp / 90 kW
@ 5,500 rpm
|
| BHP/Liter |
80 bhp / liter |
| Drivetrain |
| Chassis |
aluminium body on steel ladder frame |
| Front suspension |
live axle, semi-elliptic leaf springs, friction dampers |
| Rear suspension |
live axle, inverted quarter-elliptic leaf springs, friction dampers |
| Steering |
worm-and-wheel |
| Brakes |
drums, all-round |
| Gearbox |
4 speed Manual
|
| Drive |
Rear wheel drive |
| Dimensions |
| Weight |
750 kilo / 1,654 lbs |
| Length / Width / Height |
3,700 mm (145.7 in) / N/A / N/A
|
| Wheelbase / Track (fr/r) |
2,400 mm (94.5 in) / 1,200 mm (47.2 in) / 1,200 mm (47.2 in)
|
| Performance figures |
| Power to weight |
0.16 bhp / kg |
| Top Speed |
185 km/h (115 mph)
|
