| Engine
|
| Configuration |
Straight 6
|
| Location |
Front, longitudinally mounted
|
| Construction |
light alloy block and head
|
| Displacement |
3,485 cc / 212.7 cu in |
| Bore / Stroke |
86.0 mm (3.4 in) / 100.0 mm (3.9 in)
|
| Compression |
8.3:1 |
| Valvetrain |
2 valves / cylinder, DOHC
|
| Fuel feed |
3 Weber 42 DCOE 3 Carburettors
|
| Aspiration |
Naturally Aspirated |
| Power |
220 bhp / 164 kW
@ 5,500 rpm
|
| Torque |
343 Nm / 253 ft lbs
@ 3,500 rpm
|
| BHP/Liter |
63 bhp / liter |
| Drivetrain |
| Chassis |
steel body on ladder frame |
| Front suspension |
double wishbones, coil springs over telescopic shock absorbers, anti-roll bar |
| Rear suspension |
live axle, semi-elliptic leaf springs, anti-roll bar |
| Steering |
recirculating ball |
| Brakes |
Girling discs, all-round |
| Gearbox |
5 speed Manual
|
| Drive |
Rear wheel drive |
| Dimensions |
| Weight |
1,350 kilo / 2,976 lbs |
| Length / Width / Height |
4,680 mm (184.3 in) / 1,760 mm (69.3 in) / 1,300 mm (51.2 in)
|
| Wheelbase / Track (fr/r) |
2,600 mm (102.4 in) / 1,390 mm (54.7 in) / 1,360 mm (53.5 in)
|
| Performance figures |
| Power to weight |
0.16 bhp / kg |
| Top Speed |
220 km/h (137 mph)
|
