| Engine
|
| Configuration |
Straight 6
|
| Location |
Front, longitudinally mounted
|
| Construction |
cast-iron block, aluminium head
|
| Displacement |
1,971 cc / 120.3 cu in |
| Bore / Stroke |
66.0 mm (2.6 in) / 96.0 mm (3.8 in)
|
| Compression |
7.5:1 |
| Valvetrain |
2 valves / cylinder, OHV
|
| Fuel feed |
3 Solex 30 JF Carburettors
|
| Aspiration |
Naturally Aspirated |
| Power |
80 bhp / 60 kW
@ 4,500 rpm
|
| BHP/Liter |
41 bhp / liter |
| Drivetrain |
| Chassis |
aluminium body on steel tubular chassis |
| Front suspension |
swing axle, transverse leaf spring, oil pressure shock absorbers |
| Rear suspension |
live axle, semi-elliptic leaf springs, arm shocks |
| Steering |
rack-and-pinion |
| Brakes |
drums, all-round |
| Gearbox |
ZF 4 speed Manual
|
| Drive |
Rear wheel drive |
| Dimensions |
| Weight |
830 kilo / 1,830 lbs |
| Length / Width / Height |
3,900 mm (153.5 in) / 1,550 mm (61 in) / 1,400 mm (55.1 in)
|
| Wheelbase / Track (fr/r) |
2,400 mm (94.5 in) / 1,153 mm (45.4 in) / 1,220 mm (48 in)
|
| Performance figures |
| Power to weight |
0.1 bhp / kg |
| Top Speed |
150 km/h (93 mph)
|
