| Engine
|
| Configuration |
Cosworth / GMA 65º V12
|
| Location |
Mid, longitudinally mounted
|
| Weight |
178 kilo / 392.4 lbs |
| Construction |
aluminium alloy block and head
|
| Displacement |
4,300 cc / 262.4 cu in |
| Bore / Stroke |
84.0 mm (3.3 in) / 63.8 mm (2.5 in)
|
| Compression |
14.0:1 |
| Valvetrain |
4 valves / cylinder, DOHC
|
| Camshaft |
Gear driven
|
| Fuel feed |
Direct Fuel Injection
|
| Lubrication |
Dry sump |
| Aspiration |
Naturally Aspirated |
| Power |
720 bhp / 537 kW
@ 11,500 rpm
|
| Torque |
470 Nm / 347 ft lbs
@ 9,000 rpm
|
| Red Line |
12,100 rpm |
| BHP/Liter |
167 bhp / liter |
| Drivetrain |
| Body |
carbon-fibre composite |
| Chassis |
carbon-fibre monocoque with semi-stressed engine |
| Suspension (fr/r) |
double wishbones, push-rod actuated rising rate springs and dampers, anti-roll bar |
| Steering |
rack-and-pinion |
| Front Brakes |
ventilated carbon ceramic discs, 370mm (14.6 in), 6-pot caliper |
| Rear brakes |
ventilated carbon ceramic discs, 340mm (13.4 in), 4-pot caliper |
| Gearbox |
6 speed Manual
|
| Gear ratios |
2.833:1
2.095:1
1.577:1
1.226:1
0.971:1
0.744:1
|
| Final drive |
3.18:1 |
| Drive |
Rear wheel drive |
| Dimensions |
| Weight |
986 kilo / 2,174 lbs |
| Length / Width / Height |
4,443 mm (174.9 in) / 1,891 mm (74.4 in) / 1,149 mm (45.2 in)
|
| Wheelbase / Track (fr/r) |
2,700 mm (106.3 in) / 1,637 mm (64.4 in) / 1,572 mm (61.9 in)
|
| Fuel tank |
80 Litre (21.1 Gallon US / 17.6 Gallon Imperial)
|
| Wheels (fr/r) |
10 x 19 / 12 x 20 |
| Tyres (fr/r) |
Michelin Pilot Sport Cup 2 265/35 – ZR19 / 335/30 – ZR20 |
| Performance figures |
| Power to weight |
0.73 bhp / kg |
|
